Product Parameter

Model		Studio Size? (DWH)mm	Dimension（DWH）mm
LRHS-8000A-FB		2000×2000×2000	2480×2510×2480

Temperature range	－10℃～25℃
heating rate	-10℃～25℃≤15min （unladen）
cooling rate	25℃～-10℃≤45min （unladen）
water flow	0～50L/h (Electronic flow meter with direct display of liquid flow, adjustable)
Spraying angle	Perpendicular to box surface 45°±10°
Ice thickness	5～30mm
Air velocity	0～12m/s
Outer box material	A3 steel plate (thickness 1.2mm), CNC machine tool processing molding, the surface of the plastic spray treatment, more clean, beautiful
Inner box material	SUS304 high quality stainless steel plate, steel plate thickness 1.0mm
Insulation material	Rigid polyurethane foam + glass fiber
control meter	Taiwan “Velantone” brand operation instrument; 7-inch high-definition true-color LCD touch screen; bring you the dignity and comfort of touch and vision.
cooling system	France “Taikang” hermetic air-cooled compressor refrigeration method
Temperature Sensor	High Accuracy Pt100 Platinum Resistance Temperature Sensors
safety		Compressor low pressure/overload/high pressure alarm, fan motor overload, overall equipment timing, short circuit, phase loss, over temperature, leakage and other security
Supply Voltage		AC380V±10% 50Hz
Power		15.0kW

Industry News

How to Resolve Unstable Low Temperatures in High and Low Temperature Alternating Test Chambers

Regularly, staff should master some troubleshooting and handling methods for high and low temperature alternating test chambers. If the equipment exhibits unstable low temperatures, what causes this phenomenon, and how should we address these faults?

Cold and heat shock test chamber operation you understand?

Cold and thermal shock test chamber on the market is divided into two categories, a two-compartment type, including high-temperature region and low-temperature region, the test object were in two different temperatures in the area of the test, hot and cold alternating test; the other is a three-compartment type, in addition to high-temperature and low-temperature areas, there is also a test area, and the two-compartment different is that the three-compartment does not need to be directly in the test area for the test, only need to be through the air compression method

?How to Conduct and Assess the Sealing of a High-Temperature Test Chamber

A high-temperature test chamber is equipped with a specialized sealing system, which primarily functions to seal the test chamber door.

Ice-covered test chamber
