| light source drive |
EPS |
| Effective irradiance area |
800mm×700mm |
| Distance of light source from test surface |
1000±200mm |
| Light source power |
2000W/lamp |
| Number of light sources |
1PCS |
| Light intensity range |
150～250W/m2 |
| spectral range |
280～320nm 320～400nm |
| UVB/(UVA+UVB) |
5 to 8% |
| inhomogeneity |
≤10% |
| UVC Content |
（Ratio of integrated irradiance in the wavelength range (250-280) nm to integrated irradiance in the wavelength range (250-400) nm of UVC content ≤1%. |
| Sample temperature range |
60～70℃ (customized water-cooled structure for cell carrier table) |
| Sample temperature deviation |
≤±2℃ |
| Chamber temperature range |
20～80℃ |
| Box temperature fluctuation |
≤1℃ |
| Outer case material |
1.2mm Cold rolled steel plate with plastic spraying on both sides |
| Inner box material |
1.0mm thick SUS304 stainless steel, sunlight simulating fully reflective reflective film mounted on the side wall for secondary sealing and optical reflection control. |
| Insulation material |
10mm Thickness High Quality Insulation Material |
| Controller |
Siemens PLC Module + Touch Screen |
| Cooling method |
Air-cooled refrigeration |
| Compressor |
Taikang, France |
| Heating method |
Nickel-chromium alloy electric wire type heater |
| light source |
Holler lamp, metal halide wick, European brand.
Warranty time of the light source 2000 hours, the actual use of time greater than or equal to 3000 hours |
| irradiance meter |
Alberdi Brands |
| security protection |
Emergency stop button, sample surface temperature is too high, light source system fault alarm, power supply phase/undervoltage/overvoltage/leakage protection, fan overload, compressor overvoltage/overheat/overcurrent, heating wire over-temperature protection |
| Supply Voltage |
Voltage: 3/N/PE AC 400V±10% 50Hz Rated current: 30A |
| Power |
20.0kW |
| operating environment |
10℃～＋35℃ ? ?? ≤75% RH |
Note:
1、 the above data are measured in the use of ambient temperature of 25 ℃ and well-ventilated conditions
2、Can be customized according to the specific requirements of the user non-standard uv aging simulation test chamber etc
3、This technical information is subject to change without prior notice. |
