| Basic Specification | |||||||
| Vacuum tank size | Inner diameter of vessel ≥φ1400×mm，length of straight section ≥1200 mm | ||||||
| Heat sink dimensions | φ1200×φ1200mm | ||||||
| Heat Sink Temperature Range | -70℃～100℃（Heat sink interior） | ||||||
| Heat Sink Temperature Control Precision | ±2.0℃（Heat sink interior） | ||||||
| Limit Pressure | surpass 1×10-4Pa（+30℃） | ||||||
| Working Pressure | surpass 1.3×10-3Pa | ||||||
| Outer case material | High quality A3 steel plate electrostatic spraying | ||||||
| Inner box material | Imported high grade stainless steel SUS304 | ||||||
| Temperature sensor | PT100 Platinum resistance thermometer | ||||||
| Pressure sensor | Electronic Pressure Transmitter | ||||||
| controller | Imported “UMC” brand temperature meters | ||||||
| Cooling method | Two-machine cascade cooling | ||||||
| Safety | Compressor overpressure overload, fan motor overheating, overall equipment under phase/reverse phase, over temperature, overall equipment timing, leakage protection, overload and short circuit protection | ||||||
| Supply Voltage | AC380V±10% 50Hz | ||||||
| Power | Mainframe about 50KW | ||||||
| Operating environment | +5～+35℃、≤85%R.H | ||||||
| Note: The above data are all measured under well ventilated conditions at an ambient temperature of 25℃: 1、 the above data are in the use of ambient temperature of 25 ℃ and well ventilated conditions measured 2、Can be customized according to the user’s specific test requirements of ice-covered test chamber, ice-covered test chamber, etc. 3、This technical information, subject to change without notice |
|||||||
