| Effective irradiance area |
2000mm×1000mm |
| Light intensity range |
150～250W/m2 |
| spectral range |
280～400nm |
| UVB/(UVA+UVB) |
3～10% |
| inhomogeneity |
≤±15% |
| Sample temperature range |
60±5℃ |
| Sample temperature uniformity |
≤±5℃ |
| Outer case material |
1.2mm Cold rolled steel plate with plastic spraying on both sides |
| Inner box material |
1.0mm thick SUS304 stainless steel, sunlight simulating fully reflective reflective film mounted on the side wall for secondary sealing and optical reflection control. |
| Insulation material |
10mm Thickness High Quality Insulation Material |
| Controller |
Siemens PLC Module + Touch Screen |
| Cooling method |
Air-cooled/water-cooled refrigeration |
| Compressor |
Taikang, France |
| Heating method |
Nickel-chromium alloy electric wire type heater |
| standard configuration |
UV probes, temperature sensors, lights, lead holes, etc. |
| security protection |
Emergency stop button, sample surface temperature is too high, light source system fault alarm, power supply phase/undervoltage/overvoltage/leakage protection, fan overload, compressor overvoltage/overheat/overcurrent, heating wire over-temperature protection |
| Supply Voltage |
AC380V±10% 50Hz |
| Power |
20.0kW |
| operating environment |
5℃～＋35℃ ≤75% RH |
Note:
1、 the above data are measured in the use of ambient temperature of 25 ℃ and well-ventilated conditions
2、Can be customized according to the user’s specific test requirements.
3、This technical information is subject to change without prior notice. |
